AWS Forged Wheels for Tesla Model 3/Y

AWS Forged Wheels for Tesla Model 3/Y

Fits your Tesla Model 3/Y
Confirm your exact year, generation, and trim before ordering. Fits only Tesla Model 3/Y as listed. The same model name from another generation may use a different bolt pattern, center bore, offset, brake clearance, or load requirement.
$690.00 - $865.00
$690.00 each $2,760.00 set of 4
$690.00 - $865.00
$690.00 each $2,760.00 set of 4
0% Restocking Fee
No restocking fee is charged on eligible returns. Return shipping, used or installed items, and custom-built orders may still have exclusions, so contact us before sending anything back.
Diameter: 18"
Size: 8.5" + 30
Color: Satin Black

Atomic Wheels Lifetime Warranty

We offer a lifetime structural warranty for your peace of mind.

Fully Forged Wheels

Our wheels are crafted from premium 6061-T6 forged aluminum and engineered to exceed industry standards, ensuring exceptional performance and durability.

Accidental Damage Replacement

Street damage, road hazards, or unexpected mishaps, it happens to the best of us. Atomic Wheels supports every driver with 50% off a replacement forged wheel when the unexpected occurs. This program is limited to one full set, up to 4 wheels total, per customer and applies exclusively to forged wheels, and a photo of the damaged wheel is required to process the replacement. Drive with confidence, we’ve got you covered.

Split 5-Spoke Forged. Built for Tesla 3/Y.

The AWS is a clean split 5-spoke forged wheel for Tesla Model 3 and Model Y — sharp, sporty styling with a broad, purpose-built fitment range.
Choose the proven square setups in 18×8.5 +30 or 19×9.5 +30, or specify the new Model Y L rear widths: 19×10 +35, 21×9.5 +35, and 21×10.5 +40.
The established 18×8.5 +30 weighs ~19.6 lbs and 19×9.5 +30 ~21.4 lbs. Every AWS uses 5×114.3 PCD, a 64.1 mm center bore, and forged 6061-T6 aluminum construction.
The new rear widths are built to order for staggered Model Y L setups. Satin Black, Gloss Black, Satin Gunmetal, and Satin Bronze are the four standard finishes.
Compatible with Tesla 3/Y OEM lug nuts and TPMS sensors — no spacers or adapters needed. Each wheel carries the Atomic Wheels lifetime structural warranty and includes a color-matched center cap.

Specifications:

Application Tesla Model 3 / Model Y (square)
Size and weight 18×8.5 +30 ~ 19.6 lbs
Offset +30
PCD (Bolt Pattern) 5×114.3
Center Bore 64.1 mm
Construction Forged 6061-T6 Aluminum
Load Rating 800 KG (1763 lbs)
Note All listed weights are approximate and may vary due to normal manufacturing tolerances, with possible differences of up to 1–1.5 lbs.
AWS forged wheel render — Tesla 3/Y spec background

Insights

Meet the AWS — the split 5-spoke forged Tesla Model 3/Y wheel, in 18", 19", or 21" and four standard finishes.
AWS is the split 5-spoke forged Tesla 3/Y design in the Atomic Wheels lineup — chosen by owners who want a sharp, performance-forward look without giving up daily comfort. Three diameters cover the lineup: 18" for the lightest daily setup, 19" for square or staggered fitment, and 21" for the new Model Y L rear-width options. The 19×10 +35, 21×9.5 +35, and 21×10.5 +40 configurations are built to order. Forged 6061-T6 construction keeps unsprung weight low — 19.6 lbs per wheel at 18×8.5 +30 and 21.4 lbs at 19×9.5 +30 — while the new wider rears give the Model Y L a factory-style staggered stance. 5×114.3 PCD, a 64.1 mm center bore, OEM TPMS / lug-nut compatibility, and four standard finishes — Satin Black, Gloss Black, Satin Gunmetal, and Satin Bronze — keep AWS focused on Tesla 3/Y fitment. Covered by the Atomic Wheels lifetime structural warranty.

Built for Tesla 3/Y Drivers

Split 5-spoke forged. Three diameters. Model 3 & Model Y-ready.

5-Spoke Split Forged

AWS brings a clean split 5-spoke forged face to the Tesla Model 3 and Model Y — sharp, sporty styling that flatters every Tesla paint.

Forged & Ultra-Light

Each AWS is CNC-machined from a single forged 6061-T6 billet — denser grain, higher strength, and meaningfully lower weight than cast wheels. As light as ~19.6 lbs per wheel in the 18×8.5 +30 fitment.

Tested to Perfection

Finite Element Analysis validates the AWS split 5-spoke geometry before production. Stress mapping under simulated impacts and load cycles confirms every wheel is shipped ready for Tesla 3/Y service.

Knurled Bead Seat

Knurled bead seats add texture where the tire contacts the wheel, keeping the tire seated under hard acceleration, braking, and aggressive cornering.

Hub-Centric for Tesla 3/Y

Precision-machined 64.1 mm center bore and 5×114.3 bolt pattern fit the Tesla 3/Y hub flush — no spacers, no adapters. Tesla OEM lug nuts and TPMS sensors drop straight in.

Two Diameters

Pick the 18×8.5 +30 for daily comfort and the lightest fitment (~19.6 lbs), or step up to the 19×9.5 +30 (~21.4 lbs) for a wider stance and more aggressive styling. Both run square on Model 3 and Model Y.

Tire Fitment Guide

AWS Tesla Model 3/Y 18×8.5 +30 square setup.
Wheel Size Application Best Fit
18×8.5 +30 Model 3 (square × 4) 235/40R18
18×8.5 +30 Model Y (square × 4) 245/40R18

AWS 18" runs a square setup — four wheels at the same 18×8.5 +30 fitment. Best fit on Tesla Model 3 is 235/40R18; on Model Y, 245/40R18 keeps the OEM-style sidewall. Both fit OEM Tesla TPMS sensors and lug nuts.

Availability

If you see the "Add To Cart" button, it means our inventory is fully stocked, ensuring prompt delivery. Expect your items to be on their way within two business days after you've made your purchase.

Features

  • All Atomic Wheels are covered by our lifetime structural warranty.
  • Each set comes with color-matched Atomic Wheels center caps.

Custom order

If the design or size you are looking for is not available, we are pleased to offer you the option to create a custom order.

This allows you to tailor your wheels to your specific preferences and needs. We also provide a wide range of color options to ensure that your wheels perfectly match your vision.

More details

FAQ

What is the difference between a forged rim and a flow-formed rim?

The main difference between forged and flow-formed rims lies in their manufacturing processes and materials. Forged rims, made from 6061-T6 aluminum, are formed under extreme pressure and then precisely machined using CNC technology, resulting in ultra-strong, lightweight wheels ideal for high performance. Flow-formed rims, also known as spin-formed, start with a cast mold and are shaped using hydraulic pressure and rotation. This enhances the strength of cast rims while maintaining a more affordable price point, offering a solid balance of performance and cost.

Where do you make the wheels?

The factory where we manufacture the rims is in China. They are made with state-of-the-art technology, subjected to rigorous safety and quality control processes.

Do you ship outside of the United States?

Yes, we ship worldwide. However, purchasing a rim in stock can be expensive due to shipping costs. Therefore, we recommend placing a custom order where items are shipped directly from the factory to reduce costs. In this way you will get the same price worldwide, because the rims will be delivered from the factory.

What Tire Sizes Do You Recommend for Installing Your Rims?

We recommend sticking with OEM sizes for the best performance and fit. However, there is often some room for alternatives based on your specific needs and preferences. We’re happy to help with any questions and guide you in choosing the best tire size for your setup.

What Are Your Cancellation Policies if I Want a Refund on My Pre-Order?

If you’ve made a pre-order payment, you can cancel your order and request a refund at any time before the shipment is processed.

How Long Does It Take to Receive an Order After Making a Purchase?

We ship orders twice a week on Tuesdays and Fridays using UPS Ground. Typically, it takes 2-5 business days for wheels to be delivered after shipment.

Can I Pick Up the Rims Directly if I’m Near Your Location?

Yes, you can pick up the rims directly if you’re near our location. Please note that Texas sales tax will be applied to in-state sales.

Are Your Center Caps Compatible with the OEM Ones?

Most of our center caps are 65mm, so they are not compatible with the OEM center caps.
